Nylon Pulley

Understanding Nylon Pulleys

Nylon pulleys are wheels, typically grooved, made from polyamide (Nylon) or similar engineering plastics. They are designed to support movement and change of direction of a taut cable or belt, or transfer of power between the shaft and cable or belt. Their material properties make them advantageous in specific scenarios.

Key Advantages:

• Lightweight: Significantly lighter than metal pulleys, reducing inertia and overall system weight.
• Corrosion Resistance: Inherently resistant to rust and many chemicals, ideal for wet or corrosive environments.
• Low Friction & Self-Lubricating: Nylon has a low coefficient of friction and inherent self-lubricating properties, reducing wear on both the pulley and the belt/rope.
• Quiet Operation: Plastic material dampens noise compared to metal pulleys.
• Impact Resistance: Good toughness and ability to absorb shocks.
• Cost-Effective: Can be more economical than metal counterparts, especially when manufactured via molding for high volumes.
• Non-Marking: Less likely to mark or damage sensitive surfaces compared to metal.

Shreeji Gears: Your Ahmedabad Nylon Pulley Specialist

We combine quality materials with precise manufacturing to deliver nylon pulleys that meet your application requirements.

Why Choose Shreeji Gears for Nylon Pulleys?

• Material Expertise: Utilizing various grades of Nylon (PA6, PA66), Cast Nylon (PA6G), and other engineering plastics like Acetal (POM) based on load, speed, and environmental needs.
• Precision Machining: Capable of machining pulleys from stock shapes (rod, tube, sheet) for prototypes, low volumes, or complex designs, ensuring accurate dimensions and groove profiles.
• Molding Capabilities: Access to injection molding for cost-effective production of standard or high-volume pulleys.
• Bearing Integration: Options to supply pulleys with plain bores, keyed bores, or integrated ball bearings for smooth rotation.
• Custom Design & Manufacturing: Ability to produce nylon pulleys to custom specifications including diameter, width, groove type (V-groove, U-groove, flat), and bore configuration.
• Quality Assurance: Checks on material quality, dimensional accuracy, groove profile, bore tolerance, and overall finish.

General Technical Specifications (Customizable):

• Material: Nylon PA6, Nylon PA66, Cast Nylon PA6G, Acetal (POM), UHMWPE.
• Type: V-Belt Groove, Round Groove (U-Groove), Flat Face, Timing Profile (special order).
• Outer Diameter (OD): Wide range available (e.g., 25mm to 500mm+).
• Bore Size: Customised - Plain bore, Keyed bore, Bearing bore (standard bearing sizes).
• Width: Customised to suit belt/rope size or application needs.
• Load Capacity: Suitable for light to medium loads; specific rating depends on design and material.
• Temperature Resistance: Dependent on material (e.g., PA6 ~80°C, PA66 ~100°C continuous).

Benefit from lightweight, quiet, and corrosion-resistant operation with our Nylon Pulleys. Choose Shreeji Gears, your reliable nylon pulley manufacturer in Ahmedabad. Contact us today to discuss your plastic pulley needs!
